MANHATTAN Čtečka čárových kódů CCD 60mm USB, kontaktní
MANHATTAN Čtečka čárových kódů CCD 60mm USB, kontaktní
Improve speed, accuracy and productivity.
The Manhattan Long Range CCD Barcode Scanner delivers basic, high-quality scanning for a wide range of data collection functions to help improve routine transactions, automate paper-based processes and increase productivity. The scan engine features no moving parts for years of reliable service reading popular 1D barcodes including UPC, EAN, ASCII, MSI/PLESSEY, GS1 DataBar and more. Easy to implement and simple to use, a built-in keyboard wedge decoder sends scanned data to an active application where it appears as if it were manually typed or directly keyed into the computer. Its versatile switchable USB or PS/2 cable interface integrates with most PCs without an external power supply. With a scan rate of 500 scans per second and an accurate read range of up to 50 cm (20 in.), this model offers an effective and efficient, all-purpose daily scanning solution for less demanding point-of-sale, office and other low ambient light applications to minimize manual data entry, speed transactions and reduce errors.
Features:
Helps speed data entry, reduce errors and improve efficiency - ideal for retail transactions and automated processes
Keyboard Wedge Decoder displays data as if directly entered from keyboard
Wide scan field provides quick, accurate reads with up to 500 scans per second up to 50 cm (20 in.) away
Detects many popular symbologies including UPC, EAN and GS1 DataBar
Switchable interface integrates with most PCs
Easy to install and use without software or special training
Three-Year Warranty
Specifications:
Standards and Certifications
FCC
CE
USB
General
Supports character editing and ISP function
Light source: red LED
Width of field: 100 mm
View angle: 35°
Scanner range: 50 cm @ 20 mil / 0.5 mm, PCS 90%
Resolution: 0.1 mm (4 mil) @ PCS 0.9
Reading indicator: tone and LED
Ambient light: 10,000 lux maximum
Scan rate: 500 scans/second
Interface: USB
Switch: button
Code Support
UPC/EAN/JAN & Addon 2/5, Code 39, Code 39 Full ASCII, Code 11, Matrix 25, Code 128, Code 93, Interleave 25, Industrial 25, Codabar/MW7, MSI/PLESSEY, China Postage, Code26, LCD25, Telepen, GS1 DataBar (RSS code)
Physical
Dimensions: 14 x 7 x 9 cm (5.5 x 2.75 x 5.5 in.)
Weight: 115 g (4 oz.)
Cable length: 1.5 m (5 ft.)
Operating temperature: 0 - 50°C
Storage temperature: -20 - 70°C
Relative humidity: 20 ± 95% (non-condensing)
Housing: ABS and rubber
Electrical
Voltage: DC +5 V ± 5%
Power consumption: 150 mA
Package Contents
Long Range CCD Handheld Barcode Scanner
User manual
