CPU INTEL XEON Phi™ 7285, SVLCLGA3647-1, 1.30 GHz, 34MB L2, 68/272, tray (bez chladiče)
Popis a parametry
CPU INTEL XEON Phi™ 7285, SVLCLGA3647-1, 1.30 GHz, 34MB L2, 68/272, tray (bez chladiče)
| Code Name | Knights Mill |
| Essentials | |
| Vertical Segment | Server |
| Processor Number | 7285 |
| Lithography | 14 nm |
| Performance | |
| # of Cores | 68 |
| Processor Base Frequency | 1.30 GHz |
| Max Turbo Frequency | 1.40 GHz |
| Cache | 34 MB L2 |
| TDP | 250 W |
| VID Voltage Range | 0.550-1.200V |
| Supplemental Information | |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 384 GB |
| Memory Types | DDR4-2400 |
| Max # of Memory Channels | 6 |
| Max Memory Bandwidth | 115.2 GB/s |
| ECC Memory Supported ‡ | Yes |
| Expansion Options | |
| PCI Express Revision | 3.0 |
| PCI Express Configurations ‡ | x16 port (Port 2 and 3) may negotiate down to x8, x4, x2, or x1. x4 port (Port 1) may negotiate down to x2, or x1 |
| Max # of PCI Express Lanes | 36 |
| Package Specifications | |
| Sockets Supported | SVLCLGA3647 |
| T<sub>CASE</sub> | 72°C |
| Advanced Technologies | |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Virtualization Technology (VT-x) ‡ | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
| Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
| Intel® 64 ‡ | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® AVX-512 |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Security & Reliability | |
| Intel® AES New Instructions | Yes |
| Intel® Software Guard Extensions (Intel® SGX) | No |
| Intel® Memory Protection Extensions (Intel® MPX) | No |
| Intel® Trusted Execution Technology ‡ | No |
| Execute Disable Bit ‡ | Yes |
| Intel® Boot Guard | No |
.
ParametryPorovnání
Řada procesorů
Intel Xeon
Druh procesoru
Serverový
Vybavení procesoru
Bez chladiče
Velikost L3 cache
34
CPU INTEL XEON Phi™ 7285, SVLCLGA3647-1, 1.30 GHz, 34MB L2, 68/272, tray (bez chladiče)
