CPU INTEL XEON Phi™ 7235, SVLCLGA3647-1, 1.30 GHz, 32MB L2, 64/254, tray (bez chladiče)
Popis a parametry
CPU INTEL XEON Phi™ 7235, SVLCLGA3647-1, 1.30 GHz, 32MB L2, 64/254, tray (bez chladiče)
| Code Name | Knights Mill |
| Essentials | |
| Vertical Segment | Server |
| Processor Number | 7235 |
| Lithography | 14 nm |
| Performance | |
| # of Cores | 64 |
| Processor Base Frequency | 1.30 GHz |
| Max Turbo Frequency | 1.40 GHz |
| Cache | 32 MB L2 |
| TDP | 250 W |
| VID Voltage Range | 0.550-1.200V |
| Supplemental Information | |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 384 GB |
| Memory Types | DDR4-2133 |
| Max # of Memory Channels | 6 |
| Max Memory Bandwidth | 102 GB/s |
| ECC Memory Supported ‡ | Yes |
| Expansion Options | |
| PCI Express Revision | 3.0 |
| PCI Express Configurations ‡ | x 16 port (Port 2 and 3) may negotiate down to x8, x4, x2, or x1. x4 port (Port 1) may negotiate down to x2, or x1 |
| Max # of PCI Express Lanes | 36 |
| Package Specifications | |
| Sockets Supported | SVLCLGA3647 |
| T<sub>CASE</sub> | 72°C |
| Advanced Technologies | |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Virtualization Technology (VT-x) ‡ | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
| Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
| Intel® 64 ‡ | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® AVX-512 |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Security & Reliability | |
| Intel® AES New Instructions | Yes |
| Intel® Software Guard Extensions (Intel® SGX) | No |
| Intel® Memory Protection Extensions (Intel® MPX) | No |
| Intel® Trusted Execution Technology ‡ | No |
| Execute Disable Bit ‡ | Yes |
| Intel® Boot Guard | No |
.
ParametryPorovnání
Řada procesorů
Intel Xeon
Druh procesoru
Serverový
Počet jader
65
Velikost L2 cache
32 MB
Vybavení procesoru
Bez chladiče
Velikost L3 cache
32 MB
Počet jader
64
CPU INTEL XEON Phi™ 7235, SVLCLGA3647-1, 1.30 GHz, 32MB L2, 64/254, tray (bez chladiče)
